IP68 Waterproof Rating Traffic Barricades Security Road Blocker For Militory And Jail
Place of Origin | Guangdong, China |
---|---|
Brand Name | Securina |
Certification | FCC, CE |
Model Number | SA5000 |
Minimum Order Quantity | 1 set |
Price | USD500-50000/set |
Packaging Details | Plywood case |
Delivery Time | 5-10 working days after payment confirmation |
Payment Terms | Western Union, MoneyGram, T/T |
Supply Ability | 1000units/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xWater-proof Rating | IP68 | Applications | Auti-terrorism Road Traffic Barrier |
---|---|---|---|
Power Consumption | 3.7KW | Controller Chip | Mitsubishi PLC |
Barrier Size | 3000mm * Width 1000mm * Height 780mm | Rising Height | 500mm(accept Customized) |
High Light | mitsubishi plc control security road blocker,auti terrorism road block barrier |
IP68 Waterproof Rating Traffic Barricades Security Road Blocker For Militory And Jail
SA5000 hydraulic roadblock machine (also known as car blocker, anti-terrorism wall) uses hydraulic energy as the power to achieve the lifting function of the flip body. Its main role is to provide security for key prevention departments such as schools, communities, customs, border inspections, troops, prisons, road crossings, warehouses, and docks. To prevent unauthorized vehicles from forcibly breaking in, it has high practicability, reliability and safety. The flap barricade machine is buried under the ground, and it is necessary to first dig out the space on the ground to accommodate the base of the barricade machine. Connect the industrial AC power 380V, and install the hydraulic station to increase the dynamic of the main body through hydraulic oil transmission.
SA5000 working principle:
1. Main frame of roadblock machine:
The main frame of the roadblock machine is composed of a frame, a movable flap, a hydraulic cylinder, and two sets of balancing mechanisms. The movable flap and the frame are connected by two sets of rotating shafts, and the upper and lower earrings of the hydraulic cylinder are respectively connected between the frame and the movable flap by the rotating shaft, which is the power source for the movement of the main frame, and the two sets of balance mechanisms are connected Between the movable flap and the rack, it plays the role of load balancing and buffering.
2. Hydraulic system:
The hydraulic system consists of a drive motor, a hydraulic oil pump, a combined solenoid valve, a manual control valve, a pressure indicator, and so on.
3. Interface function description:
Ascending and descending input: the command control input interface for ascending and descending of the roadblock machine; the precise time of ascending limit and descending limit is adjustable: the limit time can be used to prevent the roadblock from operating in the blocked state for a long time and affecting its life; ascending solenoid valve, descending electromagnetic Valve: Switching and closing of the oil solenoid valve of the hydraulic pump of the roadblock machine, so as to realize the function of rising, falling and stopping operation of the roadblock machine; ascending and descending regulating valve to adjust the speed of ascent and descent
Specification of SA5000 roadblcokers:
Body specifications | length 3000mm * width 1000mm * height 780mm |
Interception width | 2700mm |
Lifting height | 500mm |
Panel thickness | 16mm |
Panel material | A3 steel |
Hair tip specifications | stainless steel material, 30mm * 60mm (diameter * length) |
Treatment process | anti-rust paint treatment |
Overall weight | about 1.2 tons |
Lifting force | 2 tons |
Waterproof rating | IP68 |
Passing pressure | 120 tons container truck can pass |
Ascent speed | 3 ~ 5S |
Securina is professional supplier, exportor, factory, manufacturer in China for traffic control barrier system like hydraulic road blocker, hydraulic security bollards, tyre killer, spike barrier, and traffic barricades.
