Alarm Mode Bottle Liquid Scanner For Iron / Aluminum Bottle Explosive Detection
|Place of Origin||Shenzhen ,China|
|Minimum Order Quantity||1 Piece|
|Packaging Details||cartons packing & wooden case|
|Delivery Time||About 3-7 working days after Payment receivingd|
|Payment Terms||L/C, T/T, Western Union, MoneyGram|
|Weight||200g (with Battery)||Detection Method||Bottles / Glass Bottles Thermal Radiation Measuring By Heat Pulse|
|Power Consumption||10W||Detection Time||Within One Second|
|Usage Environment||0~40°C 95% RH No Condensation||Limited Material Of Bottle||Can Iron, Aluminum, Plastic, Glass, Porcelain, China, Pottery|
liquid scanner airport,
Bottle Liquid Scanner for Iron and Aluminum Bottle Liquid Explosive Detection
Bottle Liquid Scanner Introduction
The liquid detector is a security instrument designed to detect flammable and explosive liquids.
It uses quasi-static computed tomography to determine the flammability and explosiveness of the liquid to be tested by measuring the dielectric constant and conductivity of the liquid to be tested.
The detector can separate flammable and explosive liquids such as liquid explosives, gasoline, acetone, ethanol, and Tianna water from safe liquids such as water, cola, milk, and juice without directly contacting the liquid.
Bottle Liquid Scanner Advantages
1. Easy to use
Handheld hazardous liquid detectors do not require any adjustment or preparation and are very easy to use. Put the device sensor close to the level of the liquid you want to check and press the button.then automatically detect.
2. Alarm Mode
A green light indicates that the liquid is not flammable. Red signal indicating the presence of potentially hazardous liquids (explosive or flammable liquids)
3. Discriminating ability
can penetrate through 8 mm thick glass and other plastic materials
Limitation of bottle Bottle size no less than: 5.5cm*1.5cm, capacity no less than 50ml
Bottle Liquid Scanner Technical Parameters
|Component||The host and the charging base|
|Single for safe liquid||Green LED light & short beep|
Identify time Metal container
|within 8 seconds|
Detection effective range
Storage temperature / humidity
-40ºC to 60ºC / 5% to 95% humidity
|Temperature of container||5-35ºC|
Bottle Liquid Scanner Applications
Usage: Check liquid explosive devices; check for bottled liquid explosives or other flammable liquids
Application: airport and rail transit passenger inspection; prison and customs; security inspection; sports and entertainment venues
Q: If i order today, how long it takes for the shipment?
A: Our delivery time is about 3-5 days after got your payment and the shipping time is about 4-10 days upon your choose the shipment
Q: Can you give me best shipping cost?
A: Sure, we give our customer best shipping cost and fast shipping time. Usually we use DHL, UPS, Fedex, TNT to keep the good quality.
Q: Are the quality of your product guaranteed?
A: We provide one year limited mfg. warranty, We have QC to control the quality one by one. So do not worry about the quality. If you got a defective item, we can refund your money or send you new item as compensation.
Bottle Liquid Scanner Showroom
